background image
301 08/01
Mounting assembly
The set comprises a yoke and a clamp
Yoke
Made of nickel silver (0,4 mm) with ground terminal (tinned)
Clamp
Spring clamp, made of nickel silver (0,4 mm)
Cap yoke
With ground terminal, made of stainless spring steel (tinned), 0,3 mm thick
Ordering code
Complete mounting assembly
B65846-J2000
Cap yoke
B65846-C2000
FEP0029-V
16,8
FEP0030-B
5,08
10,4
0,3
A
View A
17,8
15,4
12,5
3,5
18,7
0,8
5
5,5
_
1 0,1
FEP0036-T
15,6
5±0,1
1 x 0,4
Yoke
Clamp
Cap yoke
B65846
Accessories
EP 17
