1 / 1 page

Click here for the 3D model.

Dimensions

D

25mm +/-0.8mm

D2

15mm +/-0.8mm

T

12mm +/-0.8mm

Packaging Specifications

Packaging

Tray, Box

Packaging Quantity

378

Typical Component Weight

18.6 g

General Information

Series

ESD-R

Style

Round - Toroidal

Cable Type

Round Cable

Description

EMI Core Solid, For Round Cables, Toroidal Cores,

Bare Type

RoHS

Yes

Qualifications

UL94 V-2

Materials

Mn-Zn

Specifications

Temperature Range

-25/+85°C

Effective Frequency

10 MHz (AM Band Range)

ESD-R-25SH

Aliases (UECESDR25SH0000)

KEMET, ESD-R, EMI Cores, Noise Suppression

Statements of suitability for certain applications are based on our knowledge of typical operating conditions for such applications, but are not intended to constitute - and we specifically disclaim - any

warranty concerning suitability for a specific customer application or use. This Information is intended for use only by customers who have the requisite experience and capability to determine the

correct products for their application. Any technical advice inferred from this Information or otherwise provided by us with reference to the use of our products is given gratis, and we assume no

obligation or liability for the advice given or results obtained.

Generated 2/08/2024 - da6e44a1-5d1d-4e95-b3b0-941ad7606e84
