Connecting cable

NEBC-R3G4-ES-1-S-R3G4-ET

Part number: 8040455

General operating condition

Data sheet

Feature

Value

Cable designation

With label holder

Contact durability

50

Product weight

89.5 g

Electrical connection 1, function

Field device end

Electrical connection 1, design

Rectangular

Electrical connection 1, connection type

Plug

Electrical connection 1, cable outlet

Straight

Electrical connection 1, connection technology

RJ45 as per IEC 60603-7-3

Electrical connection 1, number of pins/wires

8

Electrical connection 1, occupied pins/wires

4

Electrical connection 1, type of mounting

Snap-locking

Electrical connection for input 1, connection pattern

00995653

Electrical connection 2, function

Control side

Electrical connection 2, design

Rectangular

Electrical connection 2, connection type

Plug

Electrical connection 2, cable outlet

Straight

Electrical connection 2, connection technology

RJ45 as per IEC 60603-7-3

Electrical connection 2, number of pins/wires

8

Electrical connection 2, occupied pins/wires

4

Electrical connection 2, type of mounting

Snap-locking

Electrical connection 2, connection pattern

00995653

DC operating voltage range

0 V ... 30 V

Current rating at 40° C

1.3 A

Surge resistance

0.8 kV

Note on surge resistance

Due to screening, a leakage flow of up to 20 mA is permissible.

Shield

yes

Transmission characteristics

In accordance with category 5, EN 50173, class D

According to category 5, ISO/IEC 11801, class D

Ethernet cable specification

Typ: CAT.5

Cable length

1 m

Cable characteristic

Suitable for energy chains

Connector cable test conditions

Flexural strength: as per Festo standard

Test conditions on request

Energy chain > 2 million cycles, bending radius 100 mm

Bending radius, fixed cable installation

≥40 mm

Bending radius, flexible cable installation

≥100 mm

5/13/24 - Subject to change - Festo SE & Co. KG

1/2
