MO458A/C-H-R

HIGH EFFICIENCY

LOW CURRENT

0.56" FOUR DIGIT

ORANGE LED DISPLAYS

FEATURES:

Low Cost

Low Power Requirements

High Contrast

Wide Viewing Angle

Common Anode :

MO458A-H-R

Common Cathode :

MO458C-H-R

ABSOLUT MAXIMUM RATINGS

Power Dissipation / Segment

75mW

Peak Forward Current / Segment

100mA

(Pulse Width ≤ 1mS , Duty Ratio = 1/10)

Continuous Forward current / Segment

25mA

Revers Voltage / Segment

5V

Operation Temperature Range

-20°C TO +80℃

Storage Temperature Range

-25°C TO +85℃

Solder Temperature (1/16 Inch from body)

260℃

Maximum Soldering Time(≤260°C)

5 sec

ELECTRO-OPTICAL CHARACTERISTICS ( Ta = 25℃)

PARAMETER

SYMBOL

MIN

TYP

MAX

UNIT

CONDITIONS

Average Luminous Intensity

IV

8

14

mcd

IF= 1mA

Luminous Intensity Matching Ratio

2:1

IF= 20mA

Forward Voltage Any Segment

VF

2.0

2.5

V

IF=20mA

Reverse Current Any Segment

IR

100

μA

VR=5V

Dominant Wavelength

λ

D

620

625

630

nm

IF= 20mA

Spectral Line Half Width

Δλ

17

nm

IF= 20mA

REV : B

06/5/9

MICRO
