Head changes are quick and easy without the need for recalibration.

The 28522 head adapter allows

you to weld on custom heads to

meet specific applications.

Utica® “Click” Type Torque Sensing Wrenches

Interchangeable Head “A” Size Series

s Drive Sizes: 1/4” through 3/4”

s Accept variety of heads to suit specific application requirements.

s Common center principal allows simple exchange or

replacement of heads without need for recalibration.

s Choice of micrometer adjustable or single setting (preset) models.

s Accuracy is ±4% of setting right hand and ±6% of setting left

hand within upper 80% of scale.

CHA-23

CH-150

*See page 1 for description of model change.

If calibration certification is required, request at time of purchase.

NOTE:Single setting wrenches do not have a scale and must be set on torque tester.

When ordering these preset tools, specify desired torque setting.

Micrometer Adjustable Wrench – “A” Size

Range

Graduations

Length

Weight

Model No.

in.-lb.

in.

lb.

CH-150

30–150

3.4–17

1.0

.113

228.6

1.0

0.5

If calibration certification is required, request at time of purchase.

Single Setting (Preset) Wrench – “A” Size*

Range

Length

Weight

Model No.

in.-lb.

ft.-lb.

cm-kg

in.

lb.

CHA-11

1.1–11 10–100

.8–811–115

5.75 146.1

0.3

0.1

CHA-23

2.3–23 20–200 1.7–17 23–230

7.75 196.9

0.4

0.2
