MPC5553 Microcontroller Data Sheet, Rev. 2.0
Mechanicals
Freescale Semiconductor
50
4
Mechanicals
4.1
Pinouts
4.1.1
MPC5553 416 PBGA Pinout
Figure 34, Figure 35, and Figure 36 show the pinout for the MPC5553 416 PBGA package. While the
MPC5553 and the MPC5554/MPC5565/MPC5566 are pin-compatible, the MPC5553 BGA is shown to
highlight the balls that are not connected to any signal on the MPC5553 (the eTPUB[0:31] and TSIZ[0:1]).
The alternate Fast Ethernet Controller (FEC) signals that are multiplexed with the data bus are not shown
for the MPC5553.
NOTE
Some pins have names that include functions that are not available on all
MPC55xx devices. For example, ball R25 of the 416 BGA package is named
‘SINA,’ but the MPC5553 does not have a DSPI A module. In this case, the
SINA pin can only be used for its alternate functions of GPIO[94] or
PCSC[2]. Refer to the specific device Reference Manual for functions
available on each device.
