Mechanical data

Protection class

IP20

Flammability class acc. to UL 94

V-0

Ambient temperature

-25…+70 °C

-25 ... +60 °C für UL, FM, TIIS

Storage temperature

-40…+80 °C

Dimensions

104 x 18 x 110 mm

Weight

171 g

Mounting instructions

DIN rail (NS35) or panel

Housing material

Polycarbonate/ABS

Electrical connection

4 × 3-pin removable terminal blocks, reverse polarity

protected, screw terminal

Terminal cross-section

1 × 2.5 mm²/2 × 1.5 mm²

Tightening torque

0.5 Nm
