Date: 7/19/04

SP202E Series High Performance RS232 Transceivers

© Copyright 2004 Sipex Corporation

15

Part Number

Temperature Range

Topmark

Package

SP202ECN.............................0°C to +70°C.................................SP202ECN........................................................................16–pin NSOIC

SP202ECN/TR.......................0°C to +70°C.................................SP202ECN........................................................................16–pin NSOIC

SP202ECP.............................0°C to +70°C.................................SP202ECP.........................................................................16–pin PDIP

SP202ECT.............................0°C to +70°C.................................SP202ECT.........................................................................16–pin WSOIC

SP202ECT/TR.......................0°C to +70°C.................................SP202ECT.........................................................................16–pin WSOIC

SP202EEN..........................–40°C to +85°C................................SP202EEN.........................................................................16–pin NSOIC

SP202EEN/TR....................–40°C to +85°C................................SP202EEN.........................................................................16–pin NSOIC

SP202EEP..........................–40°C to +85°C................................SP202EEP.........................................................................16–pin PDIP

SP202EET..........................–40°C to +85°C................................SP202EET..........................................................................16–pin WSOIC

SP202EET/TR.....................–40°C to +85°C................................SP202EET..........................................................................16–pin WSOIC

SP232ECN.............................0°C to +70°C................................SP232ECN..........................................................................16–pin NSOIC

SP232ECN/TR.......................0°C to +70°C................................SP232ECN..........................................................................16–pin NSOIC

SP232ECP.............................0°C to +70°C.................................SP232ECP.........................................................................16–pin PDIP

SP232ECT.............................0°C to +70°C.................................SP232ECT..........................................................................16–pin WSOIC

SP232ECT/TR.......................0°C to +70°C.................................SP232ECT..........................................................................16–pin WSOIC

SP232EEN..........................–40°C to +85°C................................SP232EEN..........................................................................16–pin NSOIC

SP232EEN/TR....................–40°C to +85°C................................SP232EEN..........................................................................16–pin NSOIC

SP232EEP..........................–40°C to +85°C................................SP232EEP..........................................................................16–pin PDIP

SP232EET..........................–40°C to +85°C................................SP232EET...........................................................................16–pin WSOIC

SP232EET/TR.....................–40°C to +85°C................................SP232EET...........................................................................16–pin WSOIC

SP233ECT............................0°C to +70°C.................................SP233ECT...........................................................................20–pin WSOIC

SP233ECT/TR......................0°C to +70°C.................................SP233ECT...........................................................................20–pin WSOIC

SP233EET..........................–40°C to +85°C................................SP233EET...........................................................................20–pin WSOIC

SP233EET/TR.....................–40°C to +85°C................................SP233EET...........................................................................20–pin WSOIC

SP310ECP............................0°C to +70°C.................................SP310ECP.........................................................................18–pin PDIP

SP310ECT............................0°C to +70°C.................................SP310ECT..........................................................................18–pin WSOIC

SP310ECT/TR......................0°C to +70°C.................................SP310ECT..........................................................................18–pin WSOIC

SP310ECA............................0°C to +70°C.................................SP310ECA..........................................................................20–pin SSOP

SP310ECA/TR......................0°C to +70°C.................................SP310ECA..........................................................................20–pin SSOP

SP310EEP..........................–40°C to +85°C................................SP310EEP..........................................................................18–pin PDIP

SP310EET..........................–40°C to +85°C................................SP310EET...........................................................................18–pin WSOIC

SP310EET/TR.....................–40°C to +85°C................................SP310EET...........................................................................18–pin WSOIC

SP310EEA..........................–40°C to +85°C................................SP310EEA...........................................................................20–pin SSOP

SP310EEA/TR.....................–40°C to +85°C................................SP310EEA...........................................................................20–pin SSOP

SP312ECP............................0°C to +70°C.................................SP312ECP..........................................................................18–pin PDIP

SP312ECT............................0°C to +70°C.................................SP312ECT...........................................................................18–pin WSOIC

SP312ECT/TR......................0°C to +70°C.................................SP312ECT...........................................................................18–pin WSOIC

SP312ECA............................0°C to +70°C.................................SP312ECA...........................................................................20–pin SSOP

SP312ECA/TR......................0°C to +70°C.................................SP312ECA...........................................................................20–pin SSOP

SP312EEP..........................–40°C to +85°C................................SP312EEP...........................................................................18–pin PDIP

SP312EET..........................–40°C to +85°C................................SP312EET............................................................................18–pin WSOIC

SP312EET/TR.....................–40°C to +85°C................................SP312EET............................................................................18–pin WSOIC

SP312EEA..........................–40°C to +85°C................................SP312EEA............................................................................20–pin SSOP

SP312EEA/TR.....................–40°C to +85°C................................SP312EEA............................................................................20–pin SSOP

Sipex Corporation reserves the right to make changes to any products described herein. Sipex does not assume any liability arising out of the

application or use of any product or circuit described hereing; neither does it convey any license under its patent rights nor the rights of others.

Available in lead free packaging. To order add "-L" suffix to part number.

Example: SP312EEA/TR = standard; SP312EEA-L/TR = lead free

/TR = Tape and Reel

Pack quantity is 1,500 for SSOP or WSOIC and 2,500 for NSOIC.

Sipex Corporation

Headquarters and

Sales Office

233 South Hillview Drive

Milpitas, CA 95035

TEL: (408) 934-7500

FAX: (408) 935-7600

ORDERING INFORMATION

DATE

REVISION

DESCRIPTION

6/2/04

A

Incorporated new package drawings with JEDEC reference.

7/19/04

A

Added typical output voltage swing value (±6V).

REVISION HISTORY
