Click here for the 3D model.

Dimensions



D

12.6mm NOM

L

31.5mm MAX

W

38.5mm MAX

T

13.5mm MAX

LL

3.2mm +/-0.4mm

Packaging Specifications



Packaging

Tray, Box

Packaging Quantity

300

Typical Component Weight

20 g

General Information



Series

FG-R05

Type

Current

Style

Through-Hole

Description

Fluxgate-Based Residual Current Sensor

Features

Open-loop, Fluxgate-Based Current Detection, PCB

Mounting

Lead

8 Pin

RoHS

Yes

REACH

Yes

Qualifications

IEC

Specifications



Temperature

Range

-40/+105°C

Voltage DC

2.25 V (PIN3, Analog Output; typical)

Power Supply

Voltage

5 V +/- 5%

Current

6 mA (MAX; DC Detection), 30 mArms (MAX, 55

Hz; AC Detection)

Sensitivity

40 V/A (PIN3, AOUT; typical)

Frequency

Range

150 Hz MAX (at -3 dB; PIN3 AOUT)

Measuring

Range

+/-50 mA

AC Alarm

Response Time

60 typical, 250 maximum (ms, @30 mArms); 20

typical, 100 maximum (ms, @60 mArms); 8

typical, 15 maximum (ms, @150 mArms); 7 typical,

10 maximum (ms, > 5 Arms)

DC Alarm

Response Time

280 typical, 1000 maximum (ms, @6 mA); 24

typical, 250 maximum (ms, @60 mA); 6 typical, 15

maximum (ms, @300 mA)

FG-R05-4BA

Aliases (USETR054BAA000)

KEMET, FG-R05, Current, Through-Hole, Residual, Open-loop, Fluxgate-

Based Current Detection, PCB Mounting
