ADN8102
Rev. C | Page 13 of 36
50Ω CABLES
2
2
TP3
HIGH SPEED
SAMPLING
OSCILLOSCOPE
50Ω CABLES
2
2
50Ω
ADN8102
AC-COUPLED
EVALUATION
BOARD
INPUT
PIN
OUTPUT
PIN
PATTERN
GENERATOR
DATA OUT
TP1
50Ω CABLES
2
2
TP2
15m CX4 CABLE
50ps/DIV
REFERENCE EYE DIAGRAM AT TP1
Figure 25. Output Pre-Emphasis Test Circuit, CX4
50ps/DIV
Figure 26. 3.25 Gbps Output Eye, 15 Meters CX4 Cable,
PE = 0 (TP3 from Figure 25)
50ps/DIV
Figure 27. 3.75 Gbps Output Eye, 15 Meters CX4 Cable,
PE = 0 (TP3 from Figure 25)
50ps/DIV
Figure 28. 3.25 Gbps Output Eye, 15 Meters CX4 Cable,
PE = Best Setting (TP3 from Figure 25)
50ps/DIV
Figure 29. 3.75 Gbps Output Eye, 15 Meters CX4 Cable,
PE = Best Setting (TP3 from Figure 25)
