PLL620-05/-06/-07/-08/-09

Low Phase Noise XO with multipliers (for 100-200MHz Fund or 3rdOT Xtal)

Universal Low Phase Noise IC’s

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 11/01/05 Page 2

PIN DESCRIPTIONS

Name

TSSOP*

Pin number

3x3mm QFN*

Pin number

Type

Description

VDD

1, 12

6,11

P

+3.3V power supply.

XIN

2

13

I

Crystal input. See Crystal Specification on page 3.

XOUT

3

14

I

Crystal output. See Crystal Specification on page 3.

OE

6

16

I

Output enable.

GND

7,8,9, 10, 14

1,2,3,4,8

P

Ground (except pin 12 on PLL620-06: DRIVSEL see below).

DRIVSEL**

-

12

I

PLL620-06 only: Drive Select Input. This pin has an internal

pull-up that will default DRIVSEL to ‘1’ when not connect to

GND. CMOS output of PLL620-06 will be high drive CMOS

when DRIVSEL is set to ‘0’, and will be standard CMOS

otherwise. The pin remains ‘Do Not Connect (DNC)’ for

PLL620-05/07/08/09.

CLKT

11

5

O

True output PECL (PLL620-08) or LVDS (PLL620-09)

(N/C for PLL620-07)

CLKC

13

7

O

Complementary output PECL (PLL620-08) or LVDS (PLL620-

09)

(CMOS out for PLL620-07).

SEL0

16

10

I

SEL1

15

9

I

SEL2

5

15

I

SEL3

4

Not available

I

Multiplier selector pins. These pins have an internal pull-up

that will default SEL to ‘1’ when not connected to GND.

* Note: PLL620-06 only available in 3x3mm QFN, PLL620-07 only available in TSSOP.

** Note: DRIVSEL on pin 12 on PLL620-06 only. The pin remains ‘Do Not Connect (DNC)’ for PLL620-05/07/08/09.

FREQUENCY SELECTION TABLE

SEL3

SEL2

SEL1

SEL0

Selected Multiplier

0

0

1

1

Fin x 8(PLL620-09 only)

1

0

1

1

Fin x 4

1

1

1

0

Fin x 2

1

1

1

1

No multiplication

Note: SEL3 is not available (always “1”) in 3x3mm package

All pins have internal pull-ups (default value is 1). Connect to GND to set to 0.
