CLM4B-RKC/AKC: PLCC4 1 IN 1 SMD LED

© 2021-2024 Cree LED. The information in this document is subject to change without notice. Cree®, the Cree logo and the Cree LED logo are registered

trademarks of Cree LED.

CLD-CT1425

REV 4

4

ORDER CODE TABLE

Color

Kit Number

Luminous Intensity (mcd)

Dominant Wavelength

Min.

Max.

Color Bin

Min. (nm)

Color Bin

Max. (nm)

Red

CLM4B-RKC-CWaXaAA3

1120

2240

RA

618

RA

630

Red

CLM4B-RKC-CWbXaAA3

1400

2240

RA

618

RA

630

Color

Kit Number

Luminous Intensity (mcd)

Dominant Wavelength

Min.

Max.

Color Bin

Min. (nm)

Color Bin

Max. (nm)

Amber

CLM4B-AKC-CWbXb353

1400

2800

A3

587

A5

596

Amber

CLM4B-AKC-CWbXb343

1400

2800

A3

587

A4

593

Notes:

•

The above kit numbers represent order codes that include multiple intensity-bin and color-bin codes. Only one intensity-bin code and one color-bin

code will be shipped on each bulk. Single intensity-bin code and single color-bin codes will not be orderable.

•

Please refer to the

HB LED Lamp Reliability Test Standards document for reliability test conditions.

•

Please refer to the

HB LED Lamp Soldering & Handling document for information about how to use this LED product safely.
