 2 / 16 page
background image
ABRACON IS
ISO9001-2015
CERTIFIED
Hidden Creek Ln Spicewood TX 78669
H
5101
Phone: 512-371-6159 | Fax: 512-351-8858
REVISED: 07-14-23
|
For terms and conditions of sales, please visit:
www.abracon.com
LTE/5G wideband External RIGHT-ANGLE Whip Antenna
AEMF1005X-H
Electrical Specification
Mechanical Specification
(1): UV Resistant optional
Environmental Specification
Parameter
Specification
Unit
Operating Frequency
617-960
1400-2700
3300-4400
4400-6000
MHz
VSWR (Typ.)
< 2.0
Peak Gain
0.1
3.6
5.1
4.8
dBi
Efficiency (Maximum)
43
64
70
61
%
Impedance
50
Ω
Polarization
Linear
Radiation Pattern (Azimuth)
Omni-directional
Input Power (Ambient 25℃)
5
W
Parameter
Specification
Dimensions
173 x 18 mm
Material
ABS
Recommended Torque for Mounting
0.565 N∙m
Color
Black
Antenna Type
Whip (Dipole)
RF Connector
SMA(M)
Parameter
Specification
Operating Temperature
-20℃ to +70℃
Storage Temperature
-20℃ to +70℃
IP Rating
Optional
RoHS Complaint
Yes
