background image
*RoHS COMPLIANT
Part
L (µH)
DCR Max
ISAT
IRMS
Number
±20%
(mΩ)
(A)
(A)
ASPI-0706HC-R47
0.33
4
10.00
7.0
ASPI-0706HC-R47
0.47
10
7.70
6.0
ASPI-0706HC-R56
0.56
10
7.70
6.0
ASPI-0706HC-1R0
1.0
17
5.35
4.4
ASPI-0706HC-1R5
1.5
20
4.52
4.2
ASPI-0706HC-2R2
2.2
37
3.52
3.1
ASPI-0706HC-3R3
3.3
43
3.00
2.9
ASPI-0706HC-4R7
4.7
55
2.60
2.2
ASPI-0706HC-6R8
6.8
90
2.20
1.7
ASPI-0706HC-100
10
110
1.92
1.5
ASPI-0706HC-150
15
175
1.50
1.2
ASPI-0706HC-220
22
255
1.20
1.0
ASPI-0706HC-330
33
370
1.00
0.82
ASPI-0706HC-470
47
480
0.87
0.72
ASPI-0706HC-600
60
700
0.70
0.60
ASPI-0706HC-680
68
740
0.66
0.58
ASPI-0706HC-101
100
1100
0.54
0.47
ASPI-0706HC-271
270
4000
0.08
0.20
ABRACON IS
ISO 9001 / QS 9000
CERTIFIED
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000 | fax 949-546-8001 | www.abracon.com
SMD POWER INDUCTORS
SMD POWER INDUCTORS
SMD POWER INDUCTORS
ASPI-0706HC SERIES
|||||||||||||||
PHYSICAL CHARACTERISTICS:
STANDARD SPECIFICATIONS:
TECHNICAL INFORMATION:
•
Lp measured at 100KHz, 0.1 VRMS
•
ISAT: is peak current for approx 30% roll-off
•
IRMS: 40°C temperature rise max
•
Operating Temperature: -40°C to +85°C
Note: All specifications subject to
change without notice.
