LAN Transformer< SMD Type: CLP Series>

Type: CLP236

Please refer to the sales offices on our website for a representative near you

www.sumida.com

2/2

◆

Specification

Turns Ratio

Part No.

RX

TX

SD68515NP-K

1CT:1CT

1CT:1CT

SD68517

1CT:1CT

1CT:1CT

SD49783

1CT:1CT

1.4CT:1CT

SD1013

1CT:1CT

1.4CT:1CT

SD49743

1CT:1CT

2CT:1CT

Parameters(SD68515NP-K)

SPECIFICATION

(TX)

(RX)

CONDITION

Inductance

(1-2)/(15-16)

350μH Min.

350μH Min.

100kHz,100mV,8mA DC bias

Insertion Loss

-1.0dB Min.

-1.0dB Min.

0.1～100MHz

-18.0dB Max.

-18.0dB Max.

1～30MHz

-18.0dB Max.

-18.0dB Max.

40MHz

-16.0dB Max.

-16.0dB Max.

50MHz

Return Loss

-12.0dB Max.

-12.0dB Max.

60～80MHz

-43.0dB Max.

-43.0dB Max.

30MHz

-43.0dB Max.

-43.0dB Max.

60MHz

Common Mode Rejection

-40.0dB Max.

-40.0dB Max.

100MHz

-55.0dB TYP.

-55.0dB TYP.

30MHz

-50.0dB TYP.

-50.0dB TYP.

60MHz

Cross Talk

-50.0dB TYP.

-50.0dB TYP.

100MHz

Hipot

(1-2)-(7-6),

(15-16)-(11-10)

AC 1500Vrms

1Minute
