ULQ200XA/XD1

Seven darlington array

Features

-40 to 105°C

loads

layout

Description

The ULQ2001, ULQ2003 and ULQ2004 are high

voltage, high current darlington arrays each

containing seven open collector darlington pairs

with common emitters. Each channel rated at

500mA and can withstand peak currents of

600mA. Suppression diodes are included for

inductive load driving and the inputs are pinned

opposite the outputs to simplify board layout.

The versions interface to all common logic

families.

These versatile devices are useful for driving a

wide range of loads including solenoids, relays

DC motors, LED displays filament lamps, thermal

print-heads and high power buffers.

The ULQ2001A/2003A and 2004A are supplied in

16 pin plastic DIP packages with a copper lead-

frame to reduce thermal resistance. They are

available also in small outline package (SO-16) as

ULQ2003D1/2004D1.

ULQ2001

General purpose, DTL, TTL, PMOS,

CMOS

ULQ2003

5V TTL, CMOS

ULQ2004

6–15V CMOS, PMOS

DIP-16

SO16

(Narrow)

www.st.com

Order codes

Part numbers

Packages

ULQ2001A

DIP-16

ULQ2003A

DIP-16

ULQ2004A

DIP-16

ULQ2003D1013TR

SO16 in Tape & Reel

ULQ2004D1013TR

SO16 in Tape & Reel
