background image
R
版本：202309J
1/12
N 沟绝缘栅双极晶体管
N-CHANNEL IGBT
JT05N065RED/SED/FED/CED
订 货 型 号 Order codes
印
记
Marking
封
装
Package
无卤-条管
Non halogen-Tube
无卤-编带
Non halogen-Reel
JT05N065RED-R-BR
JT05N065RED-R-AR
JT05N065RED
DPAK
JT05N065SED-S-BR
JT05N065SED-S-AR
JT05N065SED
TO-263
JT05N065FED-F-BR
N/A
JT05N065FED
TO-220MF
JT05N065CED-C-BR
N/A
JT05N065CED
TO-220C
封装 Package
主要参数
MAIN
CHARACTERISTICS
IC
6 A
VCE
650V
Vcesat（Vge=15V）
1.6V
用途
 逆变器
 UPS 电源
APPLICATIONS
 General purpose inverters
 UPS
产品特性
低栅极电荷
Trench FS 技术
通态压降
RoHS 产品
FEATURES
Low gate charge
Trench FS Technology
Saturation voltage
RoHS product
订货信息 ORDER MESSAGE
