TC1303A/TC1303B/TC1303C/TC1304

6.0

PACKAGING INFORMATION

6.1

Package Marking Information

* The MSOP package for this device has not

been qualified at the time of this publication.

Contact your Microchip sales office for

availability.

Second letter represents VOUT1 configuration:

Third letter represents VOUT2 configuration:

Fourth letter represents +50 mV Increments:

10-Lead MSOP*

Example:

11H0

0520

256

Example:

11H0/E

520256

10-Lead DFN

XXXX

YYWW

NNN

— 1 = TC1303B

— 2 = TC1303A

— 3 = TC1303C

— 4 = TC1304

— 1 = 1.375V VOUT1

— H = 2.6V VOUT2

— 0 = Default

XXXXXX

YWWNNN

Code

VOUT1

Code

VOUT1

Code

VOUT1

A3.3V

2.4VS1.5V

B3.2VK2.3V

1.4V

C3.1V

2.2V

U1.3V

3.0V

2.1V

1.2V

2.9V

2.0V

1.1V

2.8V

1.9V

1.0V

2.7VP1.8VY0.9V

2.6V

1.7V

Adj

2.5V

1.6V

1.375V

Code

VOUT2

Code

VOUT1

Code

VOUT2

3.3V

2.4V

1.5V

B3.2V

2.3V

—

C3.1V

2.2V

—

D3.0V

2.1V

—

E2.9V

2.0V

—

F2.8V

1.9V

—

G2.7V

1.8V

—

H2.6V

1.7V

—

I2.5V

1.6V

Code

Default

+50 mV to V2

+50 mV to V1

and V2

Legend: XX...X

Customer-specific information

Year code (last digit of calendar year)

Year code (last 2 digits of calendar year)

Week code (week of January 1 is week ‘01’)

NNN

Alphanumeric traceability code

Pb-free JEDEC designator for Matte Tin (Sn)

This package is Pb-free. The Pb-free JEDEC designator (

)

can be found on the outer packaging for this package.

Note:

In the event the full Microchip part number cannot be marked on one line, it will

be carried over to the next line, thus limiting the number of available

characters for customer-specific information.
