AD8605/AD8606/AD8608

Data Sheet

Rev. O | Page 8 of 24

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

Supply Voltage

6 V

Input Voltage

GND to VS

Differential Input Voltage

6 V

Output Short-Circuit Duration to GND

Observe Derating Curves

Storage Temperature Range

All Packages

−65°C to +150°C

Operating Temperature Range

All Packages

−40°C to +125°C

Junction Temperature Range

All Packages

−65°C to +150°C

Lead Temperature (Soldering, 60 sec)

300°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

Table 4.

Package Type

θJA1

θJC

Unit

5-Ball WLCSP (CB)

170

°C/W

5-Lead SOT-23 (RJ)

240

92

°C/W

8-Ball WLCSP (CB)

115

°C/W

8-Lead MSOP (RM)

206

44

°C/W

8-Lead SOIC_N (R)

157

56

°C/W

14-Lead SOIC_N (R)

105

36

°C/W

14-Lead TSSOP (RU)

148

23

°C/W

1

θJA is specified for the worst-case conditions, that is, a device soldered in a

circuit board for surface-mount packages.

ESD CAUTION
