DOMINANT Semiconductors
19/05/05
S SpiceLED AlInGaP SSx-CLD-v3
Page 5 of 5
Recommended Solder Pad
Note: Component is based on a new package platform, which features “Bottom Only
Terminations”. Solder joints are only formed at the bottom of the component and solder fillet will
not be observable as the sides of the component are not solderable.
Surfaces are not intended for soldering.
