Data Sheet
ADTR1107
TYPICAL PERFORMANCE CHARACTERISTICS
analog.com
Rev. C | 13 of 27
Figure 36. POUT, Gain, PAE and IDD_PA vs. Input Power, 14 GHz, Transmit
State, Path = TX_IN to ANT, VDD_PA = 5 V, IDQ_PA = 220 mA, Receive State
Off
Figure 37. Power Dissipation vs. Input Power at TA = 85°C, Transmit State,
Path = TX_IN to ANT, VDD_PA = 5 V, IDQ_PA = 220 mA, Receive State Off
Figure 38. OIP3 vs. Frequency for Various VDD_PA, POUT/Tone = 8 dBm,
Transmit State, Path = TX_IN to ANT, IDQ_PA = 220 mA, Receive State Off
Figure 39. POUT, Gain, PAE and IDD_PA vs. Input Power, 18 GHz, Transmit
State, Path = TX_IN to ANT, VDD_PA = 5 V, IDQ_PA = 220 mA, Receive State
Off
Figure 40. OIP3 vs. Frequency for Various Temperatures, POUT/Tone = 8 dBm,
Transmit State, Path = TX_IN to ANT, VDD_PA = 5 V, IDQ_PA = 220 mA,
Receive State Off
Figure 41. OIP3 vs. Frequency for Various IDQ_PA, POUT/Tone = 8 dBm,
Transmit State, Path = TX_IN to ANT, VDD_PA = 5 V, Receive State Off
