WR-03 Probe Antenna

Copyright © 2022 by Eravant

Mechanical Outline: (Unless otherwise specified, all dimensions are in inches [millimeters])

Note:

• This antenna is a mature product. The reasons for only providing simulated data can be found in

the following blog here.

• Eravant reserves the right to change the information presented without notice.

Caution:

• Any foreign objects in the antenna will cause performance degradation and possible device

damage.

-18

-16

-14

-12

-10

-8

-6

-4

-2

0

220

235

250

265

280

295

310

325

Frequency (GHz)

Simulated Return Loss vs. Frequency
