Standards Compliance

EMC

FCC Class A, ICES-003, EN 55032, EN IEC

61000-3-2:2019, EN 61000-3-3

Immunity

EN 55035

EN 300 386

Safety

EN 62368-1:2014 + A11:2017

IEC 62368-1:2014

Certi cations

BSMI (Taiwan)

CE (European Union)

KCC (South Korea)

NRTL (North America)

RCM (Australia/New Zealand)

UKCA (United Kingdom)

VCCI (Japan)

EMC

FCC Class A, ICES-003, EN 55032, EN IEC

61000-3-2:2019, EN 61000-3-3

European Union

Directives

2014/35/EU Low Voltage Directive

2014/30/EU EMC Directive

2012/19/EU WEEE Directive

2011/65/EU RoHS Directive

2015/863/EU Commission Delegated Directive

Further

Information

Product Certi cation Portal

Environmental Characteristics

Operating Temperature 2

0 to 40˚C (32 to 104˚F)

Storage Temperature

-40 to 70˚C (-40 to 158˚F)

Relative Humidity

5 to 95%

Operating Altitude

0 to 10,000 ft, (0-3,000m)

Power Supply

PWR-1511-AC-

RED/BLUE

PWR-1511-DC-

RED/BLUE

PWR-1512-AC-

RED/BLUE

PWR-2411-AC-

RED/BLUE

PWR-2411-DC-

RED/BLUE

Input Voltage

200-240V AC

-48 to -60 VDC

200-240V AC

200-240AC

-48 to 60 VDC

Typical Input Current

9.6A

35.2 A Max (-48 V)

9.6A

14A

55A Max (-48V)

Input Frequency

50/60 Hz

DC

50/60Hz

50/60Hz

DC

Output Power

1500 W

1500 W

1500 W

2400W

2400W

Input Connector

IEC 60320 C14

AWG #6 Max

IEC 60320 C14

IEC 60320 C20

AWG #6 Max

E ciency (Typical)

93% Platinum

92%

93% Platinum

93% Platinum

94%

7060X5 Series | Technical Speci cations

1. Requires EOS version 4.29.1 or later

2. Certain air ow con gurations or the use of higher power or reduced temperature range optics may reduce maximum operating temperature.

Power Supply Speci cations
