9 / 39 page

Data Sheet

ADL5519

Rev. C | Page 9 of 39

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltage: VPSA, VPSB, VPSR

5.7 V

VSET Voltage: VSTA, VSTB

0 to VP

Input Power (Single-Ended, Re: 50 Ω)

INHA, INLA, INHB, INLB

12 dBm

Internal Power Dissipation

420 mW

θJA

42°C/W

Maximum Junction Temperature

142°C

Operating Temperature Range

−40°C to +125°C

Storage Temperature Range

−65°C to +150°C

Lead Temperature (Soldering, 60 sec)

260°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the

operational section of this specification is not implied.

Operation beyond the maximum operating conditions for

extended periods may affect product reliability.

ESD CAUTION
