Product Sub Family, Side 2:

M12 Power

Type of Contact / Gender, Side 2:

female

Connector Design, Side 2:

straight

Attachment Type, Side 2:

Coupling Nut

Number of Pins, Side 2:

5

Coding, Side 2:

L

Contact Resistance, Side 2:

≤ 10 mOhm

Insulation Resistance, Side 2:

˃ 10^9 Ohm

Mating Cycles, Side 2:

≤ 100

Ambient Temperature (Operation), Side 2*:

-40 °C to +125 °C, notice derating

Protection Degree / IP Rating, Side 2**:

IP65, IP67, IP69K

Design Standard, Side 2:

IEC 61076-2-111

Pollution Degree, Side 2:

3 acc. to DIN EN 60664-1 (VDE 0110-1)

Clearance / Creepage Distance, Side 2:

DIN EN 60664-1 (2008/01); VDE 0110-1

Overvoltage Category, Side 2:

III acc. to DIN EN 60664-1 (VDE 0110-1)

Contact Base Material, Side 2:

CuNi

Contact Plating, Side 2:

Cu/Au

Contact Bearer Material, Side 2:

PBT GF

Contact Bearer Color, Side 2:

grey

Flammability Class (Contact Bearer), Side 2: UL 94 V-2

Molded Body Material, Side 2:

TPE

Molded Body Color, Side 2:

black

Flammability Class (Molded Body), Side 2:

UL 94 HB

Attachment Material, Side 2:

CuZn

Attachment Plating, Side 2:

Cu/Ni

O-Ring Material, Side 2:

FKM

Fastening Torque (Contact Screw), Side 2:

M 12x1: (50-60) Ncm, hand-tight

Approvals

UL-File:

E497237

UL:

UL 2237; cULus

VDE:

Yes

Safety & Environmental Compliance

RoHS Compliant:

Yes

Resistances

Halogenfree:

-

Oil Resistance:

Oil Res II

Notes

Note Derating:

* Notice derating

Product Characteristics:

To ensure ingress protection, please check the O-ring’s position before connecting. Improperly positioned O-ring leads to ingress protection potential failure.

Variants

Item #

Item Description

Cable Length

934853583 RST 5L-RKT 5L-1002/0,3 M SW 0.3 m

934853594 RST 5L-RKT 5L-1002/0,5 M SW 0.5 m

934853578 RST 5L-RKT 5L-1002/0,6 M SW 0.6 m

934853581 RST 5L-RKT 5L-1002/1 M SW

1 m

934853595 RST 5L-RKT 5L-1002/1,5 M SW 1.5 m

934853584 RST 5L-RKT 5L-1002/2 M SW

2 m

934853587 RST 5L-RKT 5L-1002/3 M SW

3 m

934853596 RST 5L-RKT 5L-1002/5 M SW

5 m

934853599 RST 5L-RKT 5L-1002/6 M SW

6 m

934853758 RST 5L-RKT 5L-1002/10 M SW

10 m

934853761 RST 5L-RKT 5L-1002/15 M SW

15 m

934853764 RST 5L-RKT 5L-1002/20 M SW

20 m
