HPS High Purity Pressure Gauge with Reed Switch

50 mm Dial Size

Data Sheet

All specifications are subject to change without notice.

All sales subject to standard terms and conditions.

©2022 Ashcroft Inc. 50-hps_gauge_w-switch_ds_RevA_02-10-22

ashcroft.com

info@ashcroft.com

1.800.328.8258

of 4

2

ORDERING CODE

Example:

50

HPS

G

MVS

L

60#

Size

50 - 50 mm

50

Gauge Family

HPS - High purity gauge (with reed switch)

HPS

Purity Level

G - Class 10,000

G

Process Connection

MVS - ¼ Male swivel VCR type (9∕16 -18 UNF male)

MVS

MRF - R ¼ Male

MNF - ¼ NPT Male

FVS - ¼ Female swivel VCR type (9∕16 -18 UNF female)

Process Connection Location

L - Lower

L

Range (See range table on page 3 for all standard ranges)

# - psi

60#

BR - Bar

KP - Kilopascals

MP - Megapascals
