Temperature Controller

E5C4

DIN-sized (48 x 48 mm) Temperature

Controller With Digital Setting

Compact, low-cost Temperature Controller

Incorporates proportional adjustment and reset

adjustment function.

Incorporates a plug-in socket, thus allows to

DIN-track and flush mounting.

Ordering Information

Temperature Controllers

Setting method

Indication

Control

Output

Model

method

mode

Thermocouple

(with sensor burnout detection

circuit)

Platinum resistance

thermometer

JPt100

Digital setting

Digital indication

ON/OFF

Relay

E5C4-R20K

E5C4-R20J

E5C4-R20P

Voltage (for

driving SSR)

E5C4-Q20K

E5C4-Q20J

E5C4-Q20P

P

Relay

E5C4-R40K

E5C4-R40J

E5C4-R40P

Voltage (for

driving SSR)

E5C4-Q40K

E5C4-Q40J

E5C4-Q40P

Note:

When placing an order, specify the standard temperature range and supply voltage in addition to the model number.

(e.g., E5C4-R20K

0

°C to 399°C 100/110 VAC)

Accessories (Order Separately)

Name

Model

Front Connecting Socket

P2CF-08

Back Connecting Socket (for flush mounting)

P3G-08

Watertight Cover

Y92A-48N

Temperature Ranges

Input

Thermocouple

Platinum resistance

thermometer

K (CA)

Chromel vs. alumel

J (IC)

Iron vs. constantan

JPt100

Range

°C

0 to 399

0 to 999

0 to 399

0 to 99.9

°F

32 to 799

32 to 999

32 to 999

32 to 799

32 to 199

Setting

1

°C/°F

1

°C/°F

1

°C/°F

0.1

°C/1°F
