Molded Inductor (Carbonyl)

AMPLH5030S

5.7 x 5.3 x 2.8 mm

RoHS/RoHS II Compliant

MSL Level = 1

Request Samples

Check Inventory

REVISION Initial Release :

2/27/2024

5101 Hidden Creek Ln, Spicewood TX 78669

Phone: 512-371-6159 Fax: 512-351-8858

For terms and conditions of sales, please visit:

www.abracon.com

Tape & Reel: 2000 pcs/reel

Dimensions: mm

A0

B0

W

F

P

D

K0

T

5.70±0.10 6.50±0.10 12.00±0.3 5.5±0.1 8.00±0.10 1.5±0.1 3.30±0.10 0.35±0.05

Type

A

B

C

D

13” x 12mm

12.4+2.0/-0.0 100.0±2.0 13.0+0.5/-0.2 330.0±0.3

ATTENTION: Abracon LLC’s products are COTS – Commercial-Off-The-Shelf products; suitable for Commercial, Industrial and, where designated, Automotive Applications. Abracon’s

products are not specifically designed for Military, Aviation, Aerospace, Life-dependent Medical applications or any application requiring high reliability where component failure could

result in loss of life and/or property. For applications requiring high reliability and/or presenting an extreme operating environment, written consent and authorization from Abracon

LLC is required. Please contact Abracon LLC for more information.

Packaging
