ADL5387
Rev. 0 | Page 20 of 28
RFC
1000pF
100pF
0.1µF
1000pF
100pF
0.1µF
0.1µF
100pF
VPOS
VPOS
LO
1000pF
1000pF
VPOS
ETC1-1-13
1
ADL5387
24
23
22
21
20
19
7
8
9
10
11
12
2
3
4
5
6
VPA
COM
BIAS
VPL
VPL
VPL
18
17
16
15
14
13
VPB
VPB
QHI
QLO
IHI
ILO
120nH
120nH
CAC
10µF
CAC
10µF
27µH
27µH
27µH
27µH
10µH
10µH
CAC
10µF
CAC
10µF
27µH
27µH
27µH
27µH
10µH
10µH
Figure 59. Sixth Order Low-Pass Butterworth Baseband Filter Schematic
