PACKING LIST

OPTIONAL ITEMS

ORDERING INFORMATION

Model Name

P/N

Memory 2.5 GbE 10 GbE RS-232/

422/485

USB 3.2

Gen2

USB 3.2

Gen1

USB 2.0 TPM 2.0

Power

Thermal

Temp.

ADS310-R680EIRM 770-ADS3101-000G

4 UDIMM

2

-

2

4

6

3

N/A

24-pin ATX/

8-pin ATX 12V

Active

-5 to 65°C

ADS310-Q670EIRM 770-ADS3101-100G

-

N/A

ADS310-R680EIRM 770-ADS3101-200G

2

N/A

ADS310-Q670EIRM 770-ADS3101-300G

2

N/A

ADS310-R680EIRM 770-ADS3101-400G

-

dTPM

ADS310-Q670EIRM 770-ADS3101-500G

-

dTPM

ADS310-R680EIRM 770-ADS3101-600G

2

dTPM

ADS310-Q670EIRM 770-ADS3101-700G

2

dTPM

·

1 ADS310-R680E/Q670E motherboard

·

1 COM port cable (Length: 300mm, 2 x COM ports) A81-015026-023G

·

1 Serial ATA data cable (Length: 500mm)

332-553001-005G

·

1 I/O shield

　

-2 LAN

　

-4 LAN

A49-ADS630-010G

A49-ADS630-000G

·

USB 2.0 port cable (Length: 350/398mm)

A81-001066-016G

·

USB 3.2 Gen2 port cable (Length: 350mm)

A81-001075-017G

·

COM port cable (Length: 300mm, 2 x COM ports)

A81-015026-023G

·

Serial ATA data cable (Length: 500mm, W/LOCK)

332-553001-005G

·

Serial ATA data cable (Length: 500mm, W/LOCK, 90D) A81-002128-017G

·

Thermal solution (For 35W, Height: 29.39mm)

A71-101136-000G

·

Thermal solution (For 65W, Height: 46mm)

A71-101137-000G

·

Thermal solution (For 95W/125W, Height: 110mm)

A71-101145-000G

·

Thermal solution

　

(For 10GbE LAN X550 IC Cooler, Height: 35mm)

　

(Standard X550 default have heatsink, only when with 125W

　

CPU, need change heatsink to cooler.)(opt., MOQ required)

A71-100201-000G

·

DP to HDMI Dongle

612-D2H13M-000G

·

M.2-COM4 (M.2 serial port module)

770-M2COM1-000G

·

M.2-2LAN (M.2 LAN port module)

770-M22LN1-000G

·

M.2-2PSE (M.2 PSE module)

770-M22PS1-000G

DFI reserves the right to change the specifications at any time prior to the product's release. Changes thereafter will be based on the product's revision. Please contact your

sales representative for the exact revision offered in your area. All product names mentioned are trademarks of their respective companies. © December 26, 2024 DFI Inc.
