Product: PPCUUK-R

PatchPro® - RFID Copper REVConnect Panel Upgrade Kit - 24-port -

enhanced

Product Description

PatchPro® - RFID Copper REVConnect Panel Upgrade Kit - 24-port - enhanced

Technical Specifications

Product Overview

Suitable Applications:

Horizontal and building cabling for Intelligent (RFID based) Patching. Support current and future Category 6a and 6 applications, such as: 10GBase-T (10 Gigabit Ethernet),

1000Base-T (Gigabit Ethernet), 100 Base-T, 10 Base-T, FDDI, ATM

Physical Characteristics (Overall)

Height:

15.4 mm

Width:

449 mm

Depth:

4 mm

Packaging:

Individually packaged in a box.

Connectors

Materials

Description

Material

Color

RFID antenna 24 RFID antennas Black

LED

24 LEDs

Electrical Characteristics

Current Rating:

1.500 A

Temperature Range

Storage Temperature Range: -20°C To +85°C

Operating Temperature

Range:

0°C To +40°C

Standards

ISO/IEC Compliance:

ISO/IEC 11801-1:2017

TIA/EIA Compliance:

TIA 568-C.3

Applicable Environmental and Other Programs

Environmental Space:

Indoor

EU Directive 2011/65/EU

(RoHS 2):

Yes

EU CE Mark:

Yes

Related Part Numbers

Related Parts:

PatchPro Connectivity

History

Update and Revision:

Revision Number: 0.12 Revision Date: 11-21-2024
