Product: PPL4MPON

PatchPro 24-Port (48-Fiber) LC OM4 iPLM Ready MPO Panel Set (Polarity A)

Product Description

PatchPro 24-Port (48-Fiber) LC OM4 iPLM Ready MPO Panel Set (Polarity A)

Technical Specifications

Product Overview

Environmental Space:

Indoor

Suitable Applications:

Panel for Intelligent Ready (RFID based) Patching. Support current and future applications, such as: 10GBase-T (10 Gigabit Ethernet), 1000Base-T (Gigabit Ethernet), 100

Base-T, 10 Base-T, FDDI, ATM

Construction

Weight:

1.5 kg

Height:

44 mm

Width:

482 mm

Depth:

300 mm

Physical Specifications

Max Capacity:

24 Duplex LC Ports

Mechanical Characteristics

Maximum Insertion Loss:

0.6 dB

Front Connection:

Flush

Footprint/Type:

LC

Temperature Range

Operating Temperature Range:

-10°C To +60°C

Installation Temperature Range: -10°C To +60°C

Storage Temperature Range:

-10 to 75°C

Product Material

Materials

Description

Material

Color

Type

Panel drawer and cover - With 4 MPO and 2 cable entry ports

Anodized aluminum

Metal silver color 1.5 mm thick

Panel frontplate (including screws) - LC Front Plate Metal work 2nd generation Steel, textured powder coated Black (Ral 9005)

1.5 mm thick

Adapters - 24 LC Duplex PC - Mounted

Plastic

Erica Violet

4 MPO Adapters - Mounted

Plastic

Erica Violet

4 Hydra Cables - Mounted

900 µm

2 rubber grommets and 3 twister kits

Standards

TIA/EIA Compliance:

TIA 568-C.3

ISO/IEC Compliance:

ISO/IEC 11801-1:2017

EU Directive 2011/65/EU

(RoHS 2):

Yes
