RPM7237-R series
Photo Link Module
Rev.B
1/6
IR Receiver Module
RPM7237-R series
RPM7237-R series are remote control receiver module. Small-sized, light-weight, and low voltage operated (from 2.7V)
modules have been achieved by using resin mold.
Center frequency
36.7kHz
Applications
All household electric appliances such as TV, DVD, air conditioner and audio equipment.
Features
1) Low voltage operation. (VCC=2.7 to 3.6V)
2) Low current consumption. (ICC=0.3mA, VCC=3V)
3) Superior anti VCC noise characteristics.
4) 5 types of holders available to each set.
RPM7237-R series
Sub carrier
frequency
SIDE VIEW
TOP VIEW
RSIP-A3 (H9)
12.0mm
RPM7237-H9R
∗Under development
RSIP-A3 (H8)
7.2mm
RPM7237-H8R
RSIP-A3 (H13)
15.0mm
∗RPM7237-H13R
RSIP-A3 (H5)
9.6mm
RPM7237-H5R
RSIP-A3 (H4)
15.9mm
RPM7237-H4R
Height to lens
36.7kHz
Absolute maximum ratings (Ta = 25
°C)
Parameter
Symbol
Limits
Unit
VCC
6.3
−30 to +100
2.0
V
Output current
Tstg
IO
°C
mA
Supply Voltage
Storage temperature
−10 to +75
Topr
°C
Operating temperature voltage
Recommended operating conditions (Ta = 25
°C)
Parameter
Symbol
Min.
Typ.
Max.
Unit
Supply voltage
VCC
3.0
V
2.7
3.6
