INPUT AND OUTPUT CAPACITOR: RECOMMENDED SPECIFICATIONS

Table 2.

Parameter

Symbol

Test Conditions/Comments

Min

Typ

Max

Unit

CAPACITANCE1

TA = −40°C to +125°C

Input

CIN

7.0

10

µF

Output

COUT

7.0

10

µF

Regulator

CREG

0.7

1

µF

Reference

CREF

0.7

1

µF

CAPACITOR EQUIVALENT SERIES RESISTANCE (ESR)

RESR

TA = −40°C to +125°C

CIN, COUT

0.001

0.5

Ω

CREG, CREF

0.001

0.2

Ω

1 The minimum input and output capacitance must be >7.0 µF over the full range of the operating conditions. Consider the full range of the operating conditions in the

application during device selection to ensure that the minimum capacitance specification is met. X7R and X5R type capacitors are recommended. Y5V and Z5U capacitors

are not recommended for use with any LDO.
