NYP

Model Number Structure

The purpose of this model number legend is to provide understanding of the meaning of specifications from the model number.

Models are not available for all combinations of code numbers.

* Please consult your OMRON representative for details.

Item

Description

Option / Description

1

Series name

NYP: NY- series Industrial Panel PC

2

Processor

27: Intel® CoreTM i7-7820EQ 7th generation CPU with fan unit for active cooling

35: Intel® Core™ i5-7300U

7th generation CPU with fanless cooling

65: Intel® Core™ i5-1145GRE 11th generation CPU with fanless cooling

13: Intel® Core™ i3-1115GRE 11th generation CPU with fanless cooling

2C: Intel® Celeron® 3965U

7th generation CPU with fanless cooling

2A: Intel® Atom® x5-E3940 with fanless cooling

3A: Intel® Atom® x6425RE with fanless cooling

3

Main memory

1: 2 GB, non-ECC

2: 4 GB, non-ECC

3: 8 GB, non-ECC

4: 16 GB, non-ECC

5: 32 GB, non-ECC

6: 64 GB, non-ECC

C: 8 GB, ECC

D: 16 GB, ECC

4

Expansion slots

0: No PCIe slot

1: 1 PCIe slot

5

Operating system

0: No operating system

3: Windows 10 IoT Enterprise 2016 LTSB - 64 bit

4: Windows 10 IoT Enterprise 2019 LTSC - 64bit

5: Windows 10 IoT Enterprise 2021 LTSC - 64 bit

F: Windows 10 IoT Enterprise 2019 LTSC - 64 bit + FH software

6

Storage

0: No disk

1: 128 GB, CFast 3DTLC

2: 256 GB, CFast 3DTLC

3: 512 GB, CFast 3DTLC

5: 64 GB, CFast MLC

6: 128 GB, CFast MLC

7: 256 GB, CFast MLC

9: 64 GB, SSD SLC

C: 320 GB, HDD

D: 500 GB, HDD

E: 1 TB, HDD

F: 128 GB, SSD 3DTLC

G: 256 GB, SSD 3DTLC

H: 512 GB, SSD 3DTLC

K: 128 GB, SSD MLC

L: 256 GB, SSD MLC

M: 500 GB, SSD MLC

P: 1 TB, SSD 3DTLC

7

Optional interface

0: No optional interface

1: RS-232C

2: DVI-D

4: DisplayPort++

6: NY Monitor Link

8

Display size (diagonal)

12: 12.1 inch model, 1280 x 800 pixels, 24 bit full color

15: 15.4 inch model, 1280 x 800 pixels, 24 bit full color

19: 18.5 inch model, 1,920 x 1,080 pixels, 24 bit full color

9

Display ratio

W: Wide

10

Touchscreen

C: Projected Capacitive Touch type

11

Frame type

1: Panel mounted

12

Material/finish

0: Aluminum, black paint

1: Aluminum, Nickel plating

13

Built-in options

0: None

14

Logo

0: OMRON

2: Customized logo

*

NYP

@@ - @ @ @ @ @ - @@ @ @ @ @ @ @

12

3

4

5

6

7

8

9

10 11 12 13 14
