Data Sheet

ADL6331

SPECIFICATIONS

analog.com

Rev. B | 4 of 54

V33AMP1 voltage (V33AMP1) = V33AMP1A voltage (V33AMP1A) = V33AMP2 voltage (V33AMP2) = V33AMP2A voltage (V33AMP2A) = V33FUSE

voltage (V33FUSE) = 3.3V. TA = 25°C, fixed gain mode, DSA attenuation = 0 dB, source resistance (RS) = 50 Ω differential, and load resistance

(RL) = 50 Ω single-ended, unless otherwise noted.

Table 2. Specifications

Parameter

Test Conditions/Comments

Min

Typ

Max

Units

FREQUENCY RANGE (ADL6331-A)

0.38

8.0

GHz

Power Gain

Full Fixed Gain Mode1

0.38 GHz

12.7

dB

1.0 GHz

15.7

dB

2.0 GHz

15.9

dB

4.0 GHz

15.5

dB

8.0 GHz

14.4

dB

AMP1 Bypass Attenuation Mode2: AMP2 = Fixed Gain Mode

0.38 GHz

−14.6

dB

1.0 GHz

−9.5

dB

2.0 GHz

−9.2

dB

4.0 GHz

−9.6

dB

8.0 GHz

−11.5

dB

AMP2 Bypass Attenuation Mode2: AMP1 = Fixed Gain Mode

0.38 GHz

− 12.0

dB

1.0 GHz

−7.1

dB

2.0 GHz

−7.0

dB

4.0 GHz

−7.1

dB

8.0 GHz

−7.8

dB

Full Bypass Attenuation Mode2

0.38 GHz

−36.3

dB

1.0 GHz

−31.9

dB

2.0 GHz

−31.7

dB

4.0 GHz

−32.8

dB

8.0 GHz

−33.4

dB

FREQUENCY RANGE (ADL6331-B)

1.0

15.0

GHz

Power Gain

Full Fixed Gain Mode1

1.0 GHz

15.2

dB

2.0 GHz

16.0

dB

4.0 GHz

15.8

dB

8.0 GHz

14.6

dB

12.0 GHz

14.8

dB

15.0 GHz

14.7

dB

AMP1 Bypass Attenuation Mode2: AMP2 = Fixed Gain Mode

1.0 GHz

−10.0

dB

2.0 GHz

−9.1

dB

4.0 GHz

−9.4

dB

8.0 GHz

−11.6

dB

12.0 GHz

−13.5

dB

15.0 GHz

−17.5

dB

AMP2 Bypass Attenuation Mode2: AMP1 = Fixed Gain Mode

1.0 GHz

−7.5

dB

2.0 GHz

−6.6

dB

4.0 GHz

−6.7

dB

8.0 GHz

−7.3

dB

12.0 GHz

−7.5

dB

15.0 GHz

−9.0

dB

Full Bypass Attenuation Mode2

1.0 GHz

−31.7

dB

2.0 GHz

−31.3

dB

4.0 GHz

−32.1

dB
