Data Sheet

ADL6331

TYPICAL PERFORMANCE CHARACTERISTICS

analog.com

Rev. B | 20 of 54

ADL6331-B

V33AMP1 = V33AMP1A = V33AMP2 = V33AMP2A = V33FUSE = 3.3 V, TA = 25°C, fixed gain mode, DSA attenuation = 0 dB, RS = 50 Ω differential, and

RL = 50 Ω single-ended, unless otherwise noted. Refer to the AMP1 and AMP2 Trimming and Tuning section for OIP3 optimization.

Figure 53. Gain vs. Frequency, 1.0 dB DSA Steps

Figure 54. Gain vs. Frequency, 1.0 dB DSA Steps, AMP2 Bypass

Figure 55. Gain vs. Frequency, 1.0 dB DSA Steps, AMP1 Bypass

Figure 56. Gain vs. Frequency, 1.0 dB DSA Steps, AMP1 and AMP2 Bypass

Figure 57. Gain vs. Frequency for Various Supplies

Figure 58. Gain vs. Frequency for Various Temperatures
