Fixed Inductors (Chip Inductors)

– 102 –

1

10

100

1000

10

100

1000

10000

10

20

30

40

50

60

70

80

10

100

1000

10000

1N0

2N2

22N

10N

47N

R10

2N2

4N7

10N

22N

47N

R10

Frequency (MHz)

Frequency (MHz)

■ Typical Characteristics

● Q-Frequency Characteristics (Typ.)

●L-Frequency Characteristics (Typ.)

Part No

Inductance (nH)(Typ.)

Q(Typ.)

800MHz 900MHz

1.8GHz

2.0GHz

2.4GHz

800MHz 900MHz

1.8GHz

2.0GHz

2.4GHz

ELJRF1N0 FB

0.95

0.95

0.96

0.96

0.97

31.8

33.8

47.2

49.6

54.0

ELJRF1N2 FB

1.23

1.24

1.24

1.25

1.25

31.0

33.0

43.4

45.6

49.7

ELJRF1N5 FB

1.51

1.51

1.53

1.53

1.54

32.9

34.9

48.6

50.9

55.4

ELJRF1N8 FB

1.85

1.85

1.87

1.88

1.90

31.1

33.1

45.9

48.1

52.1

ELJRF2N2 FB

2.11

2.12

2.15

2.16

2.19

28.3

30.1

41.6

43.6

47.2

ELJRF2N7 FB

2.63

2.63

2.68

2.70

2.73

28.0

28.7

39.6

41.4

44.7

ELJRF3N3 FB

3.27

3.28

3.35

3.37

3.42

29.9

31.7

43.7

45.7

49.2

ELJRF3N9 FB

3.73

3.74

3.82

3.85

3.91

29.7

31.5

43.4

45.4

48.8

ELJRF4N7 FB

4.77

4.78

4.92

4.96

5.07

33.9

35.9

49.0

51.1

54.6

ELJRF5N6 FB

5.70

5.70

5.80

5.90

6.20

30.0

31.0

40.0

41.0

42.8

ELJRF6N8 FB

6.91

6.93

7.21

7.29

7.51

28.9

30.7

41.3

42.7

45.0

ELJRF8N2 FB

8.31

8.33

8.73

8.86

9.19

31.0

32.9

43.9

45.3

47.4

ELJRF10N FB

10.21

10.25

10.77

10.94

11.37

29.8

31.6

42.1

43.5

45.6

ELJRF12N FB

12.3

12.3

13.1

13.3

14.0

30.8

32.6

42.9

44.1

45.4

ELJRF15N FB

15.3

15.4

16.5

16.9

17.9

28.8

30.4

39.5

40.4

41.2

ELJRF18N FB

18.4

18.6

20.2

20.8

22.3

31.1

32.8

41.6

42.1

41.7

ELJRF22N FB

23.7

23.9

27.5

28.8

32.5

31.3

32.9

39.6

39.4

37.2

ELJRF27N FB

28.3

28.5

32.8

34.4

38.8

28.4

29.9

36.0

35.8

33.7

ELJRF33N FB

34.6

35.1

43.4

46.8

57.5

28.4

29.7

33.7

32.9

29.2

ELJRF39N FB

40.8

41.4

49.9

53.2

63.3

25.6

26.9

31.1

30.5

27.5

ELJRF47N FB

49.6

50.3

62.1

66.8

81.8

22.7

23.8

26.9

26.2

23.2

ELJRF56N FB

58.4

59.1

69.9

74.1

86.2

23.8

25.0

28.9

28.3

25.6

ELJRF68N FB

71.9

72.9

90.4

97.5

119.9

22.3

23.3

25.4

24.3

20.4

ELJRF82N FB

86.6

87.8

107.8

115.7

140.6

21.9

22.9

25.5

24.6

21.3

ELJRFR10 FB

105.5

106.8

128.2

136.5

161.3

21.0

21.9

25.0

24.4

21.9

: Symbol of Tolerance

■ Reference Date

■ ELJRF Type

Sep. 2010
