CC1000

SWRS048A

Page 1 of 55

CC1000

Single Chip Very Low Power RF Transceiver

Applications

• Very low power UHF wireless data

transmitters and receivers

• 315 / 433 / 868 and 915 MHz ISM/SRD

band systems

• RKE – Two-way Remote Keyless Entry

• Home automation

• Wireless alarm and security systems

• AMR – Automatic Meter Reading

• Low power telemetry

• Game Controllers and advanced toys

Product Description

CC1000 is a true single-chip UHF trans-

ceiver designed for very low power and

very low voltage wireless applications. The

circuit is mainly intended for the ISM

(Industrial, Scientific and Medical) and

SRD (Short Range Device) frequency

bands at 315, 433, 868 and 915 MHz, but

can easily be programmed for operation at

other frequencies in the 300-1000 MHz

range.

The main operating parameters of

CC1000

can be programmed via a serial bus, thus

making

CC1000 a very flexible and easy to

use transceiver.

In a typical system

CC1000 will be used together with a

microcontroller and a few external passive

components.

CC1000 is based on Chipcon’s SmartRF®

technology in 0.35

µm CMOS.

Features

• True single chip UHF RF transceiver

• Very low current consumption

• Frequency range 300 – 1000 MHz

• Integrated bit synchroniser

• High sensitivity (typical -110 dBm at 2.4

kBaud)

• Programmable output power –20 to

10 dBm

• Small size (TSSOP-28 or UltraCSP™

package)

• Low supply voltage (2.1 V to 3.6 V)

• Very few external components required

• No external RF switch / IF filter

required

• RSSI output

• Single port antenna connection

• FSK data rate up to 76.8 kBaud

• Complies with EN 300 220 and FCC

CFR47 part 15

• Programmable frequency in 250 Hz

steps makes crystal temperature drift

compensation possible without TCXO

• Suitable

for

frequency

hopping

protocols

• Development kit available

• Easy-to-use software for generating the

CC1000 configuration data
