STDRIVE102BH 데이터시트(PDF) 1 Page - STMicroelectronics

부품명 STDRIVE102BH
상세설명  Triple half-bridge gate driver with programmable currents
PDF  56 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
제조업체  STMICROELECTRONICS [STMicroelectronics]
홈페이지  http://www.st.com
Logo STMICROELECTRONICS - STMicroelectronics

STDRIVE102BH 데이터시트(HTML) 1 Page - STMicroelectronics

  STDRIVE102BH Datasheet HTML 1Page - STMicroelectronics STDRIVE102BH Datasheet HTML 2Page - STMicroelectronics STDRIVE102BH Datasheet HTML 3Page - STMicroelectronics STDRIVE102BH Datasheet HTML 4Page - STMicroelectronics STDRIVE102BH Datasheet HTML 5Page - STMicroelectronics STDRIVE102BH Datasheet HTML 6Page - STMicroelectronics STDRIVE102BH Datasheet HTML 7Page - STMicroelectronics STDRIVE102BH Datasheet HTML 8Page - STMicroelectronics STDRIVE102BH Datasheet HTML 9Page - STMicroelectronics Next Button
Zoom Inzoom in Zoom Outzoom out
 1 / 56 page
background image
Features
•
Operating voltage from 6 to 50 V
•
Gate drivers with programmable current capability up to:
–
1 A source current
–
2 A sink current
•
High robustness against below-ground and overshoot
•
Charge pump for 100 % duty cycle operation with dedicated undervoltage
lockout protection
•
Flexible power management:
–
12 V LDO linear regulator with dedicated undervoltage lockout
protection
–
3.3 V LDO linear regulator with dedicated undervoltage lockout
protection
•
Standby mode for low consumption less than 50 nA
•
Thermal shutdown protection
•
VDS monitoring for safe driving operation of the power MOSFETs
•
Flexible analog front-end:
–
Up to three wide-bandwidth operational amplifiers
–
Up to three high-speed comparators
•
Dual control modes:
–
ENx/INx
–
INHx/INLX with interlocking
•
Matched propagation delay for all channels
•
Logic inputs up to 5 V, TTL compatible
Applications
•
Battery supplied power tools
•
Portable vacuum cleaners
•
E-bikes
•
Industrial automation
•
Robotics
•
Pumps and fans
Description
The STDRIVE102BH and the STDRIVE102H are triple half-bridge gate drivers
suitable for 3-phase brushless motor driving.
The STDRIVE102BH/H is the optimal solution for battery supplied motor driver
applications such as power tools, vacuum cleaner and small appliances thanks to its
very efficient stand-by mode, that strongly reduce the current consumption when the
device is not active.
VFQFPN 48L, 6x6x1 mm
VFQFPN 40L, 5x5x1 mm
Product status link
STDRIVE102BH
STDRIVE102H
Product label
Triple half-bridge gate driver with programmable currents
STDRIVE102BH, STDRIVE102H
Datasheet
DS14545 - Rev 1 - March 2025
For further information, contact your local STMicroelectronics sales office.
www.st.com
