 4 / 8 page
background image
Data Sheet
ADL8143-CSL
SPECIFICATIONS
analog.com
Rev. 0 | 4 of 8
RADIATION TEST AND LIMIT SPECIFICATIONS
Electrical characteristics at VDD = 1.5V, IDQ = 35mA, RBIAS = 487Ω, and TCASE = 25°C, unless otherwise noted.
Table 4. Radiation Test and Limit Specifications
Parameter
Min
Typ
Max
Unit
FREQUENCY RANGE
10
14
GHz
GAIN
26.5
28.5
dB
OUTPUT
OP1dB
6.5
8.5
dBm
SUPPLY CURRENT
IDQ
35
mA
IDQ_AMP
33.2
mA
IRBIAS
1.8
mA
SUPPLY CURRENT
VDD
1.2
1.5
3.5
V
