LB Y87S, LT Y87S
2006-04-10
11
Empfohlenes Lötpaddesign
8) 9) Seite 16
IR Reflow Löten
Recommended Solder Pad
8) 9)
page 16
IR Reflow Soldering
OHPY1315
0.8 (0.031)
Component location on pad
Bauteil positioniert
Padgeometrie für
CA
verbesserte Wärmeableitung
heat dissipation
Paddesign for improved
Lötstopplack
Solder resist
C
A
