JB5CS03FL00N-RK 데이터시트(PDF) 2 Page - Japan Aviation Electronics Industry, Ltd.

부품명 JB5CS03FL00N-RK
상세설명  Circular connector, IP68, Small size, waterproof, panel-to-cable, push-pull mating structure, solder type, 3 pos., Panel mount receptacle
PDF  3 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
제조업체  JAE [Japan Aviation Electronics Industry, Ltd.]
홈페이지  http://www.jae.com
Logo JAE - Japan Aviation Electronics Industry, Ltd.

JB5CS03FL00N-RK 데이터시트(HTML) 2 Page - Japan Aviation Electronics Industry, Ltd.

  JB5CS03FL00N-RK Datasheet HTML 1Page - Japan Aviation Electronics Industry, Ltd. JB5CS03FL00N-RK Datasheet HTML 2Page - Japan Aviation Electronics Industry, Ltd. JB5CS03FL00N-RK Datasheet HTML 3Page - Japan Aviation Electronics Industry, Ltd.
Zoom Inzoom in Zoom Outzoom out
 2 / 3 page
background image
Contact Arrangement Code
　　
Contact Size X No. of Contacts
#22 X 3
Contact Size
#22
Applicable Wire Size (mm2)
　　
Applicable Wire Insulation
Diameter (mm)
　　
Finish of Contact in Connecting
Area
Gold plating over Nickel
Total Current Rating (A)
　　
Dielectric Withstanding
Voltage (VACr.m.s. 1minute)
1,500
Insulation Resistance
(megaohm min.)
1,000
Contact Resistance (milliohm
max.)
　　
Operating Temperature Range
(deg. C)
-55 deg. C to +85 deg. C
Alternative Insert Position
(deg.)
0
Connector Color
Chromium plating
Applicable Contacts
　　
Applicable Accessory
　　
Contact, Strip/ Loose Piece
　　
Tool Type
　　
Accessory Type
　　
RoHS compliant
10 substances (2011/65/EU, (EU)2015/863)
REACH compliant
Remarks
Jam nut type
Notice
