JB5CS08AN00-RK

Features

Circular connector, IP68, Small size, waterproof, panel-to-cable, push-pull mating structure, solder type, 8 pos., Panel mount

receptacle (Through-hole)

Part Number

JB5CS08AN00-RK

Status

Active

Number of Positions

8 pos.

Contact Pitch (mm)

Rated Current (A)

2A / pos. max.

Rated Voltage (V)

200 VAC

Applicable Specifications

Waterproof/ Non-waterproof

IP68 (Mated, Unmated)

Applications

-

Connector Type

Panel mount receptacle (Through-hole)

Connector Style

Contact Type

Socket

Termination Style

Through-hole

Applicable Wire Size (AWG)

#28 max.

Applicable Shell Size

S

Coupling Style

Push- pull lock

Product Details
