Schottky Barrier Diode

DF25SC6M

www.iscsemi.com

1

FEATURES

· Low VF

· Pb Free Terminal

· SMD

APPLICATIONS

· PFC

· AC/DC Section of SMPS

· Choppers Motor Drives

ABSOLUTE MAXIMUM RATINGS(Ta=25℃)

SYMBOL

PARAMETER

VALUE

UNIT

VRRM

VRWM

VR

Peak Repetitive Reverse Voltage

Working Peak Reverse Voltage

DC Blocking Voltage

60

V

IF(AV)

Average Rectified Forward Current

12.5×2

A

IFSM

Non-repetitive Peak Surge Current

(50Hz sine, I cycle)

300

A

TJ

Max. Junction Temperature

150

℃

Tstg

Storage Temperature Range

-40~150

℃

THERMAL CHARACTERISTICS

SYMBOL

PARAMETER

MAX

UNIT

Rth j-c

Thermal Resistance,Junction to Case

1.6

℃

/W

2

3

1
