RXP,RXN
RD(0–9)
RBC0
10-BitCode
td(Rx latency)
10-BitCode
b0
b1
b2
b3
b4
b5
b6
b7
b8
b9
CL
5pF
CL
5pF
50 W
50 W
t
r
t
f
CLOCK
80%
50%
20%
t
r
t
f
2V
0.8V
DATA
1.4V
TLK1221
SLLS713C – FEBRUARY 2007 – REVISED SEPTEMBER 2009....................................................................................................................................... www.ti.com
Figure 7. Receiver Latency, TBI Normal Mode Shown
Figure 8. Transmitter Test Setup
Figure 9. TTL Data I/O Valid Levels for AC Measurement
10
Submit Documentation Feedback
Copyright © 2007–2009, Texas Instruments Incorporated
Product Folder Link(s): TLK1221
