Power Inductors <SMD Type: CDH Series>

Type: CDH40D11/SMB

Please refer to the sales offices on our website for a representative near you

www.sumida.com

1/2

◆

Product Description

・

4.2×4.2mm Max.(L×W), 1.2mm Max. Height.

・

Inductance range: 0.74～33μH.

・

Rated current range: 0.36～2.65A.

・

Custom design is available.

◆

Feature

・

Magnetically shielded construction.

・

Ideally used in Mobilephone,PDA,MP3,DSC/DVC,HDD,etc as DC-DC Converter inductors.

・

Dropping impact reinforced types.

・

RoHS Compliance

◆

Dimensions (mm)

◆

Land Pattern (mm)
