Absolute maximum ratings and operating conditions

Table 1. Absolute maximum ratings (AMR)

Symbol

Parameter

Value

Unit

VCC

Supply voltage(1)

1.

All voltage values are measured with respect to the ground pin

6

V

Vin

Input voltage(2)

2.

The magnitude of the input signal must never exceed VCC + 0.3 V / GND - 0.3 V

GND to VCC

Toper

Operating free-air temperature range

-40 to + 85

°C

Tstg

Storage temperature

-65 to +150

Tj

Maximum junction temperature

150

Rthja

Thermal resistance junction to ambient(3)

3.

The device is protected from over heating by a thermal shutdown active @ 150° C

200

°C/W

Pd

Power dissipation

Internally limited(4)

4.

Exceeding the power derating curves during a long period provokes abnormal operating conditions

W

ESD

Human body model(5)

5.

Human body model: 100 pF discharged through a 1.5 k

Ω resistor between two pins of the device, done for

all couples of pin combinations with other pins floating.

2kV

Machine model(6)

6.

Machine model: a 200 pF cap is charged to the specified voltage, then discharged directly between two

pins of the device with no external series resistor (internal resistor < 5

Ω), done for all couples of pin

combinations with other pins floating.

200

V

Latch-up

Latch-up immunity

Class A = 200

mA

Lead temperature (soldering, 10 s)

260

°C

Output short-circuit protection

Internally limited(7)

7.

Implemented short-circuit protection protects the amplifier against damage by short-circuit between

positive and negative outputs and between outputs and ground.

A

RL

Minimum load resistor

3.2

Ω
