BYV52PI 데이터시트(PDF) 1 Page - STMicroelectronics |
|
|
|||||||||||||||||||||||||||||
BYV52PI 데이터시트(HTML) 1 Page - STMicroelectronics |
|
|
1 / 6 page  BYV52/PI ® October 1999 Ed : 2C HIGH EFFICIENCY FAST RECOVERY RECTIFIER DIODES SOT93 (Plastic) BYV52-200 SUITED FOR SMPS VERY LOW FORWARD LOSSES NEGLIGIBLE SWITCHING LOSSES HIGH SURGE CURRENT CAPABILITY HIGH AVALANCHE ENERGY CAPABILITY INSULATED VERSION TOP3I : Insulating voltage = 2500 V DC Capacitance = 12 pF DESCRIPTION FEATURES Dual center tap rectifier suited for switchmode power supply and high frequency DC to DC converters. Packaged in SOT93, or TOP3I this device is intended for use in low voltage, high frequency inverters, free wheeling and polarity protection applications. isolated TOP3I (Plastic) BYV52PI-200 Symbol Parameter Value Unit IF(RMS) RMS forward current Per diode 50 A IF(AV) Average forward current δ = 0.5 SOT93 Tc=110 °C Per diode 30 A TOP3I Tc=90 °C Per diode 30 IFSM Surge non repetitive forward current tp=10ms sinusoidal Per diode 500 A Tstg Tj Storage and junction temperature range - 40 to + 150 - 40 to + 150 °C °C ABSOLUTE MAXIMUM RATINGS Symbol Parameter Value Unit VRRM Repetitive peak reverse voltage 200 V A1 K A2 1/6 |
