EP.MERSEN.COM

PF 10

P

F

or correct, without notice, any information contained in this datasheet.

Current-limiting A2K and A6K fuses provide excellent protection

where high available short circuit currents exist. These fast-acting

fuses are particularly good for branch/feeder circuits and back-up

protection.

FEATURES/BENEFIT S:

•

Rejection style design prevents replacement by other fuse classes

•

Fiberglass body provides dimensional stability in harsh industrial

environments

•

Easy-to-read imprint label for quick recognition and replacement

•

High degree of current limitation for low peak let-thru current

RATINGS:

A2K

•

Volts: 250VAC / DC

•

Amps: 1 to 600A

•

IR: 200kA I.R. AC, 20kA I.R. DC

A6K

•

Volts: 600VAC / 300VDC

•

Amps: 1 to 600A

•

IR: 200kA I.R. AC,

20kA I.R. DC

HIGHLIGHT S

•

Highly current-limiting

•

Fast-acting

•

Rejection style

APPLIC ATIONS:

•

Loadcenters

•

Panelboards

•

Switchboards

•

Bus duct

•

Feeder circuits

•

Non-inductive loads

•

Lighting circuits

APPRO VALS:

•

UL listed to standard 248-12

File E2137

•

CSA certified to standard

C22.2 No. 248.12

•

Self-certified for DC per UL248

A2K-R & A6K-R

Fast Acting/Class RK1

UL/CSA LISTED POWER FUSES

THESE FAST-ACTING FUSES DELIVER A HIGH DEGREE

OF CURRENT LIMITATION WHERE YOU NEED IT MOST
